CTS Turbo B8/B8.5 A4/A5/AllRoad 1.8T/2.0T TFSI Direct Fit Intercooler

Code: CTS-B8-DF
Sale!

US$699.99 US$559.99

In Stock

Included Warranty

12 Months
All CTS Turbo products are warrantied against manufacturing defects for a period of 12 months from the date of invoice. Warranty does not cover abuse, misuse, consequential damages, normal wear and tear, improper installation, or damages resulting from racing. Warranties only apply to the original owner. If a product is found defective the customer will receive, at the discretion of CTS Turbo, free repair or replacement. Warranty on other manufacturers will be processed under their terms.

Description

CTS Turbo is proud to announce our Direct fit FMIC for the B8/B8.5 1.8T/2.0T platform.

The OEM B8 and B8.5 intercoolers deliver underwhelming performance, this platform benefits greatly from an intercooler upgrade. Vehicles at stock boost levels up through Stage 1-2 and Big Turbo applications will all see a large improvement over the factory equipped hardware.

This giant intercooler core is almost 2 times larger than stock but does not cause a noticeable pressure drop, 1-2psi was measured. Cast aluminum end tanks attach to our high-flow silicon hoses seamlessly to ensure a boost-leak free fit that will last! This part meets our extensive quality control and pressure testing.

We also include a high-flow turbo outlet fitting that removes the factory turbo muffler found on stock turbos.

For vehicles equipped with Audi Drive Select (ADS); you will have to order an Additional oil cooler for ADS.

ADS cooler is visible through the top right corner of grille. Usually comes on cars with Dynamic Steering and Dynamic Suspension.

Features:

  • Efficient high-denstity bar and plate construction
  • Internal air-directing fins provide smooth flow and minimize pressure drop
  • Low-pressure drop
  • Designed using the latest 3D scanning technology
  • Cast aluminum end tanks result in superior flow
  • High-flow silicon outlet hoses
  • Bonus 2″ turbo muffler delete for the turbocharger outlet
  • Compatible with factory turbo, K04 turbo kits and BOSS kits

Fitment:

  • Audi A4 1.8/2.0 TFSI 2009-2016
  • Audi A5 1.8/2.0 TFSI 2009-2016
  • Audi A4 Allroad 2.0 TFSI 2009-2016
  • Audi A5 Sportback 2.0 TFSI 2009-2016

Installation Guide

Additional information

Weight 42 lbs
Dimensions 40 × 10 × 25 in
