SBC B5 S4 / RS4 2.7T Clutch Kit

Code: 70286-B5S4

US$525.00

In Stock

Included Warranty

12 Months
All CTS Turbo products are warrantied against manufacturing defects for a period of 12 months from the date of invoice. Warranty does not cover abuse, misuse, consequential damages, normal wear and tear, improper installation, or damages resulting from racing. Warranties only apply to the original owner. If a product is found defective the customer will receive, at the discretion of CTS Turbo, free repair or replacement. Warranty on other manufacturers will be processed under their terms.

Description

Street Series

The Street Series kits are intended for cars that are mainly driven on the street and occasionally at the track. All Street Series clutch kits are designed with full face clutch linings bonded to a Marcel type disc to give you a smoother engagement than any puck style clutch. Full face clutches are available with the same friction materials as the puck style clutches and will not sacrifice torque.


Rally Series: HD Stage 1:

DSCF1445.JPG (81277 bytes) Rally kits contain a modified high performance pressure plate and heavy duty organic disc. The linings on this disc are premium woven medium metal content lining. This facing has a 9000 RPM burst and dissipates heat quicker then any other organic lining on the market. This kit generates 1/3 more torque then stock. Also included in the kit are a throw-out bearing, pilot bearing, and alignment tool.






TX Series: HD Stage 2:

DSCF1446.JPG (81084 bytes) TZ kits contain a modified high performance pressure plate with a heavy duty Kevlar® lined disc. The metal backed Kevlar® linings provide a smooth engagement and have the torque capacity to handle high horse power, high revving engines . These clutch kits maintain a stock feel at the pedal and have unmatched durability. Also included in the kit are a throw out bearing, pilot bearing, and alignment tool.  Front and back of metal backed TZ Kelvar® lining. The steel backing gives this lining the ability to spin up to 12,000 rpm.


OFE Series: HD Stage 3:

The OFE kit combines the newest technology in linings: A Feramic full face lining on the flywheel side and a “Medium Metal” content Organic lining on the pressure plate side. This combination runs cooler and significantly extends clutch life. The OFE series clutch not only engages very smooth, it has the torque capacity of other Stage 4 clutch kits. This state of the art kit is what everybody wants when it comes to street performance.
DSCF1448.JPG (81631 bytes) These are the front and back facing on the OFE series. Feramic against the flywheel for superior holding power and organic “Medium Metal” content lining engaging on the pressure plate side for an ultra smooth feel.




SS vs. HD:

The SS series kits use the same friction materials on the disc but have an extreme clamp load pressure plate with a pedal effort increase up to 50%. The result is a more aggressive, stronger clutch that can handle most any  performance upgrades. Look for the SS series clutch kits to fit your application in our catalog.




O
FE Series: SS Stage 4:

The OFE SS kit combines the newest technology in linings: A Feramic full face lining on the flywheel side and a “Medium Metal” content Organic lining on the pressure plate side. This combination runs cooler and significantly extends clutch life. The OFE SS series clutch not only engages very smooth, it has the torque capacity of other Stage 5 clutch kits.
DSCF1448.JPG (81631 bytes) These are the front and back facing on the OFE series. Feramic against the flywheel for superior holding power and organic “Medium Metal” content lining engaging on the pressure plate side for an ultra smooth feel.




FE Series: SS Stage 5:

The FE SS series is the ultimate when it comes to delivering maximum torque to the street and strip driven car. With Feramic on both sides of the disc, the clutch delivers a more positive engagement.  Because Feramic clutch material displaces heat extremely fast it will give you maximum clutch life and a consistent feel each time you shift.

Track Series

The Track Series is intended for cars mainly used on the race track. The puck style clutches deliver a much more aggressive engagement than our full face series. Puck style clutches will give you quick starts and fast shifting.

DXD Puck Series: SS Stage 4:

DSCF1442.JPG (82265 bytes) The DXD SS Puck kit contains a extreme clamp load pressure plate, and a 6 button, true dual friction clutch disc. By using ceramic buttons on the flywheel side of the disc and 100% Kevlar® buttons on the pressure plate, this disc will provide all the holding power required by today’s serious racers.


DXD-F: SS Stage 5:

DSCF1447.JPG (81610 bytes) Our DXD-F SS series is the ultimate in puck style clutches. Our Feramic product incorporates graphite and cindered iron for the highest torque friction product in the industry. The DXD-F SS is intended only for the serious racer. Feramic will greatly reduce wear to the flywheel and pressure plate casting making this puck clutch  out last the competition.  This Feramic product exemplifies what Dynamax Extreme Duty clutch kits are all about.



Additional information

Weight 30 lbs

Model

Generation

Make Model Year Generation
Make Model Year Generation
AUDI RS4 1999 - 2001 B5
AUDI S4 1999 - 2001 B5
