Supertech VW / Audi 2.0T FSI/TSI Gen1, Gen2, Gen3 BEEHIVE Spring and Retainer Kit

Description

These images are representative, actual product images may differ.

Beehive Valve Spring Kit for FSI/TSI/TFSI 2.0T engines (4-cylinder)

BEEHIVE Spring Kit for 16V 2.0T engines (EA113, EA888.1, EA8882 and EA888.3). Latest revision from Supertech, with slightly less pressure than previous SPRK-A2416-BE2 kit.

Beehive springs allow for the use of a smaller, lighter retainer allowing for higher RPM and more valve control.

Seat Pressure: 91 @37.40 ; 105 @36
Open Pressure: 190 @ 10 ; 202@ 10
Max Lift: 11.00mm
Coil Bind: 24.90mm
Outer Spring ID: 12.70mm (top)
Retainer: RET-A2416-N2
Kit Spring qty: 16
Kit Spring: SPR-A2416N-BE
Rate: 9.8
Outer Spring OD: 24.00mm (bottom)
Retainer qty: 16

Fitment for all EA113, EA888.1, EA888.2 and EA888.3 engines
